AQUA XL EP ACS certified level regulator

Description:

AQUA XL EP

This ACS certified float level switch is constructed with special components with internal ballast for use in drinking water applications.

As the liquid level reaches the unit, the mechanical switch inside will tilt, thus closing or opening a circuit connected to an electrical panel.

Thanks to its +/- 10° switching angle the float can ensures a very precise level measurement thanks. Also it can be used in high or low alarm.

However, the AQUA XL EP level regulator is not suitable for agitated liquids by the presence of an agitator or in a water tower. Please choose our float switch model: ATS 165 EP, ACS certified.

For pump control of several levels with several pumps in calm liquid with a float level switch equipped with a stainless steel adjustable ballast, choose the SOBA EP, ACS certified.

AQUA XL EP, ACS CERTIFIED technical data sheet

(PDF 814Ko)

Advantages:

ECONOMIC

ECOLOGIC

RELIABLE

WATERPROOF

ACS CERTIFIED

CUSTOMIZABLE

Application:

Technical caracteristics:

Switching angle	+/- 10°
Allowed fluid density	0,95 to 1,05
Power supply	12, 24, 48 VAC /VCC - 250 VAC /VCC 50/60 Hz
Cut out power	16 (6) A (16 A resistive; 6 A inductive)
Maximum pressure	3,5 bars
Allowed temperature	85 °C

Protection index	IP 68
Housing material	Copolymer Polypropylene ACS certified
Cable 3 x 1 mmm²	PVC certified ACS
Weight	765 g
Dimenssion	Height : 165 mm - Diam : 100 mm
Ballast	internal ballast
Cable lenght	5, 6, 10,13, 15, 20, 25 et 30

+ de détails

Important

WATCH OUT FOR PENALTIES !A Sanitary Conformity Certificate (ACS) is required in many countries for any device in contact with drinking water meant for human consumption. In France the ACS Certificate is mandatory since 2006. For more information about the ACS Certificate, please see our Drinking Water (ACS) section.
