Membrane level detector - SOLIBA MS

Description :

The SOLIBA MS is a small membrane level detector for non-explosive areas which detects the high, low and / or intermediate level in the hoppers or small containers and the indications of stuffing in the endless wires and other types of transport.

Positioned inside of the hopper or silo, the SOLIBA MS membran level detector is actuated by a membrane. The operation of the detector is the result of the pressure exerted by the bulk material against the membrane. It can be used for powdery and granular products with easy flow and with a specific weight between 0.3 and 2.5 t / m³.
The choice of a SOLIBA MS level detector is highly recommended to secure your installations for a minimum cost, even if they are equipped with other types of equipment such as rotary paddles, vibrating blades, capacitive probes, ultrasound, radars, etc. .

ATMI
 SOLIBA MSMALL Fiche technique détaillée  (PDF 933Ko)

Directions for use:

  • The SOLIBA MS level detector must be installed on the vertical wall of the silo in order to ensure optimal operation.

LEVEL DETECTION
JAMS DETECTION

Applications :

Technical caracteristics :

Operation By pressure
Use Silo filling stop
Power supply 250 VAC / VCC 50/60 Hz
Cut out power 16 A
Allowed temperature -10 ºC ... +60 ºC
Protection index IP 44
Housing material ABS casing
Membrane Nbr or Viton
Weight 200 g
Dimenssion Height : 50 mm - Diam : 90 mm
Product density 0.3 t / m3 ... 2.5 t / m3
